2.132,00 € Vat excl.
| Input | |
| Max.InputVoltage | 1,100 V |
| Max. Current perMPPT | 30 A |
| Max. Short Circuit Current perMPPT | 40 A |
| StartVoltage | 200 V |
| MPPT OperatingVoltage Range | 200 V ~ 1000 V |
| Rated Input Voltage | 600 V |
| Number of Inputs | 8 |
| Number of MPP Trackers | 4 |
| Output | |
| Rated AC Active Power | 50,000 W |
| Max. AC Apparent Power | 55,000 VA |
| Rated Output Voltage | 400 Vac / 480 Vac, 3W+(N) + PE |
| Rated AC Grid Frequency | 50 Hz / 60 Hz |
| Rated Output Current | 72.2 A @ 400Vac, 60.1 A @ 480Vac |
| Max. Output Current | 79.8 A @ 400Vac, 66.5 A @ 480Vac |
| Efficiency | |
| Max.Efficiency | 98.5% |
| European Efficiency | 98.0% |
| Communication | |
| Display | LED Indicators, Bluetooth + APP |
| RS485 | Yes |
| Smart Dongle | WLAN/Ethernet via Smart Dongle-WLAN-FE(Optional) 4G/3G/2GviaSmartDongle-4G(Optional) |
| Protection | |
| Input-side Disconnection Device | Yes |
| Anti-islanding Protection | Yes |
| AC Overcurrent Protection | Yes |
| DC Reverse-polarity Protection | Yes |
| PV-array String Fault Monitoring | Yes |
| DC Surge Arrester | Type II |
| AC Surge Arrester | Type II |
| Residual Current Monitoring Unit | Yes |
| ArcFault Protection | Yes |
| Optimizer Compatibility | |
| DC MBUS Compatible Optimizer | MERC-1100/1300W-P |
| General data | |
| Operating Temperature Range | -25°C ~ 60°C (-13°F ~ 140°F) |
| Cooling Method | Smart Air Cooling |
| DC Connector | Amphenol Helios H4 |
| AC Connector | Waterproof Connector + OT/DT Terminal |
| Protection Degree | IP 66 |
| Topology | Transformerless |
| Nighttime Power Consumption | ≤ 5.5W |
| Dimensions (W x H x D) | 640 x 530 x 270 mm (25.2 x 20.9 x 10.6 inch) |
| Weight (with mounting plate) | 49 kg |
