| Input |
| Recommended max. PV power |
30,000 Wp |
| Max. input voltage |
1,100 V |
| Max. input current per MPPT |
30 A (two string) / 20 A (single string) |
| Max. short-circuit current |
40 A |
| Start-up voltage |
200 V |
| MPPT Operating voltage range |
200 V ~ 1000 V |
| Rated input voltage |
600 V |
| Max. number of inputs |
4 |
| Number of MPP trackers |
2 |
| Output |
| Rated output power |
20,000 W |
| Max. apparent power |
22,000 VA |
| Rated output voltage |
220 Vac / 380 Vac, 230 Vac / 400 Vac, 239.6 Vac / 415Vac, 3W + N + PE |
| Rated AC grid frequency |
50 Hz / 60 Hz |
| Max. output current |
33.6A/380Vac
31.9A/400Vac
30.8A/415Vac |
| Adjustable power factor |
0.8 capac ... 0.8 indut |
| Features & Protection |
| Overvoltage Category |
PV Ⅱ/AC Ⅲ |
| Input-side disconnection device |
Yes |
| Anti-islanding protection |
Yes |
| AC over-current protection |
Yes |
| DC reverse-polarity protection |
Yes |
| String fault detection |
Yes |
| DC surge protection |
TYPE II |
| AC surge protection |
CLASS II |
| Standard compliance |
| Safety |
EN/IEC 62109-1, EN/IEC 62109-2 |
| Grid connection standards |
G99, EN 50549, CEI 0-21, CEI 0-16, VDE-AR-N-4105, VDE-AR-N-4110, C10/11, ABNT, VFR 2019, UNE 217001, UNE 217002, RD 244, TOR D4, IEC61727, IEC62116 |
| Optimizer compatibility |
| DC MBUS compatible optimizer |
SUN2000-450W-P, SUN2000-450W-P2, SUN2000-600W-P, MERC-1300W-P, MERC-1100W-P |
| General data |
| Display |
LED Indicators; Integrated WLAN + FusionSolar App |
| Communication |
RS485; WLAN/Ethernet via Smart Dongle-WLAN-FE (Optional) 4G / 3G / 2G via Smart Dongle-4G (Optional) |
| Operation temperature range |
-25 ~ + 60 °C (-13 °F ~ 140 °F) |
| Cooling |
Raffreddamento ad aria intelligente |
| Degree of protection |
IP 66 |
| Dimensions (W x H x D) (incl. mounting plate) |
546 x 460 x 228mm (21.5 x 18.1 x 9.0 inch) |
| Weight (with mounting plate) |
21kg (46.4 lb) |
