The MultiPlus-II will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur.

The second level will boost the output of a generator or shore side supply with power taken from the battery.

The MultiPlus-II is the key component in a Victron ESS system, providing the flexibility to combine with MPPT Solar Chargers or Grid-tie PV Inverters.

For examples and more detailed information see the ESS Design & installation manual.

In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads.

This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption.

Monitor and control your Multi and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop or PC for multiple operating systems.

There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your Multi to auto starting a back generator and more...

INVERTER

• Input voltage range: 19-33 V
• Output:
  Output voltage: 230 VAC ± 2%
  Frequency: 50 Hz ± 0,1%
• Cont. output power at 25°C: 3000VA / 2400W
• Cont. output power at 40°C: 2200W / 1700W
• Peak power (W): 5500W
• Maximum efficiency: 94%
• Zero load power: 13W
• Zero load power in AES mode: 9W
• Zero load power in Search mode: 3W

ENCLOSURE

• Material & Colour: steel, blue RAL 5012
• Protection category: IP 21
• Battery-connection: M8 bolts
• 230 V AC-connection: Screw terminals 13 mm² (6 AWG)
• Weight: 26 kg
• Dimensions (hxwxd): 506 x 275 x 147 mm

CHARGER

• AC Input:
  Input voltage range: 187-265 VAC;
  Input frequency: 45 – 65 Hz
• Charge voltage 'absorption': 28.8V
• Charge voltage 'float': 27.6V
• Storage mode: 26.4V
• Charge current house battery: 70A
• Battery temperature sensor: Yes
• Programmable relay: Yes
• Protection:output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, 230 VAC on inverter output, input voltage ripple too high
• VE.Bus communication port: For parallel and three phase operation, remote monitoring and system integration
• General purpose com. port: Yes, 2x

GENERAL

• Interfaces: VE.Bus Smart dongle (optional)
• Remote on-off: Yes
• Operating temperature range: -40 to +65°C (fan assisted cooling)
• Humidity (non-condensing): max 95%
